Iwata Revolution HP-CR3 Gravity Feed Dual Action Airbrush

Iwata Revolution HP-CR3 Gravity Feed Dual Action Airbrush


Shop Local

Shop Local Dealers near you for more competitive prices.


Iwata Revolution HP-CR3 Gravity Feed Dual Action Airbrush spray chart image
Iwata Revolution Series airbrushes deliver soft, effortless coverage and quality atomization at low air pressures making them a great choice for fine spray and general purpose airbrushing.

Exclusive to Revolution Series, HP-CR3 Gravity Feed Dual Action airbrush features a unique, comfort handle and an R3 Head System. If you love how our Revolution BR sprays but crave a larger fluid cup, then the Iwata Revolution CR3 is for you. Iwata Revolution HP-CR3 has a 0.24 oz 7 ml fluid cup with lid that is ideal for color mixing.

Iwata's spring-steel needle resists breakage and our needle packings are solvent resistant for longevity. We include an Iwata nozzle spanner that may be used to remove the nozzle for cleaning and Iwata Lube, which lubricates the needle and main lever mechanism.

Effortless Coverage is one of our 5 Ways to Spray categories. Who Sprays with Effortless Coverage? Makers and creators who...

  • Spray medium range detail and coverage area
  • Want great atomization at low air pressures
  • Have beginner to high-level airbrush skills
  • Want many feature and model options
  • Are hobbyists or professional painters

Doesn't sound like you? Check out all of our 5 Ways To Spray categories or take our Airbrush Selector Quiz to find your next Iwata!

Technical Info

Spray Performance CategoryEffortless Coverage
Spray ScaleFine to Wide
Optimal Working Pressure20 - 30 psi (0.14 - 0.21 Mpa)
Head SystemR3 - Needle, Needle Cap, Nozzle, Nozzle Cap
Nozzle TypeScrew-On
Feed StyleGravity
Paint Capacity0.24 oz (7.0 ml)
Handle TypeComfort
Net Weight (lbs)0.24
Net Weight (kg)0.11
Assembled Dimensions (in)1.10 x 5.87 x 2.64
Assembled Dimensions (mm)28 x 149 x 67

User Manual
