Iwata Maxx Jet 110-120V Airbrush Compressor

Iwata Maxx Jet 110-120V Airbrush Compressor


Shop Local

Shop Local Dealers near you for more competitive prices.


Take your art on-the-go with Iwata Maxx Jet. This powerful airbrush compressor is built-into a convenient rolling-case that has storage space for your stuff. It is ideal when you need low to high output from 1-60 psi. The dual manifold air compressor is set up to operate one airbrush and one mini spray gun such as Iwata Eclipse G Series and RG-3.

Iwata Maxx Jet is equipped with a pressure gauge that displays the tank pressure in the 2.5 liter air storage tank and the gauge on the regulator displays the working pressure. The moisture filter traps condensation within the cup delivering clean, dry air. Using the adjustment levers on the manifold, you can independently regulate the air pressure to each air hose, giving you total control. Auto shut-off technology enables the compressor to shut itself off when not in use. This feature upgrade is known to lengthen the life span of the compressor motor because it reduces the workload of the motor over time.  The powerful two pole 1/6 hp motor is oil-less, has a 2.5 liter air storage tank and stays cool with the built-in internal cooling fan. The air intake filter protects the motor from dust and particulates and is designed for easy-access filter cleaning. The protective travel case includes a convenient retractable handle. The detachable top opens a handy storage tray and the case contains two built-in storage drawers. Turn the unit on and off with a convenient switch mounted into the outer case and when you are finished you can detach the power cord for convenient mobility.

Iwata Maxx Jet includes two braided air hoses. One is fitted for Iwata airbrushes and the other for Iwata Mini Spray Guns. Also included is an airbrush and spray gun holder and regulator holder. We include a replacement air intake filter and adapter fittings for Badger, Aztek and Paasche brand airbrushes. Also included is a detailed operation manual.

Optional expansion storage tray sold separately.

Technical Info

Pressure CategoryLow to High
Voltage Requirement (V)110 - 120V 60 Hz
Plug TypeB
Approved RegionNorth America
Amps (A)2.10
Wattage (W)250
Horsepower (hp)1/16
Decibels (dB)72
Air Flow @ 50 PSI (CFM)
Air Flow @ 50 PSI (LPM)
Air Flow @ 60 PSI (CFM)1.41
Air Flow @ 60 PSI (LPM)40
Max Pressure (psi)60
Max Pressure (MPa)0.41
Working Pressure (psi)1 - 60
Working Pressure (MPa)0.01 - 0.41
Air Storage Tank Capacity (L)2.50
Air Pressure RegulatorYes
Net Weight (lbs)33
Net Weight (kg)15
Assembled Dimensions (in)23 x 13 x 14
Assembled Dimensions (mm)584 x 330 x 356

User Manual
